IBM 46XX Interface

PowerScan

PBT7100 Cordless

46xx Number of Host Resets

Specifies how many consecutive resets are processed before the reader starts a five-second

period to allow the user to enter Programming Mode and configure the reader. The con-

figurable range for this feature is 1 to 15 resets.

ENTER/EXIT PROGRAMMING MODE

46xx Number of Host Resets = 1

46xx Number of Host Resets = 2

46xx Number of Host Resets = 3

46xx Number of Host Resets = 4

46xx Number of Host Resets = 5

46xx Number of Host Resets = 6

DEFAULT
