BT Beeper Indications
Product Reference Guide
387
BT Beeper Indications
Beep Type Description Behavior
Acknowledge (ACK) Label
A label has been sent to the Base Station, which
has accepted the data and responded. Control via
ACK NAK Options on page 57.
1 beep.
Duration, frequency and volume vary, since
these are all configurable for this feature.
Label Rejected
Label data sent is rejected by the Base Station
(responds with NAK). Control via ACK NAK
Options on page 57.
2 beeps at low frequency.
Transmission Error
A label has been sent to but not received by the
Base Station (ACK timeout occurred).
Control via Indicate Transmission Failure on
page 67.
Beep will sound
High-low-high-low.
Link Successful
The Linking process has completed successfully
between a reader and Base Station (or PC).
Beep will sound
Low-med-high.
Link Unsuccessful
The Linking process has completed (timed out)
without connecting to a Base (or PC).
Beep will sound
High-low-high-low.
Unlink The reader has unlinked from the Base Station.
Beep will sound
High-medium-low.
Paging Base Station is paging the reader.
5 beeps at high volume and currentGood
Read Beep Frequency setting.
BT Reader FRU
The reader will sound this upon detecting aField
Replaceable Unit (FRU) error at startup.
1 long error tone
a
.
a.
Upon hearing a long error tone at startup, press the trigger to hear the FRU error beep sequence described in Error Codes
on page 389.
Disconnect
Sounds when the reader disconnects from the
Base Station due to out of range, low power, etc.
Control via Disconnect Beep on page 345.
Beep will sound
High-medium-low.
(Same as Unlink)
Good Read Disconnected
A label is read while disconnected, and BT Poll
Rate on page 354 is disabled.
1 long beep at low frequency.
Good Read Unlinked A label is read while unlinked.
Beep will sound
High-low-high-low.
Leash mode
The Handheld has disconnected, and BT Leash
Alarm on page 346 is enabled.
Beep will sound at high volume, low fre-
quency for the count specified in BT Leash
Alarm on page 346.
Low Battery The battery is getting low 10 beeps at high frequency
Battery Shutdown
The battery has reached a critical low level and
the handheld will shut down.
Beep will sound
High-medium-low
