DataBar (RSS)

Product Reference Guide

393

DataBar (RSS)

DataBar-14

NOTE

DataBar variants must be enabled to read the barcodes below (see

DataBar

(RSS) on page 393

10293847560192837465019283746029478450366523

(DataBar Expanded Stacked)

1234890hjio9900mnb

(DataBar Expanded)

08672345650916

(DataBar Limited)

55432198673467

(DataBar Omnidirectional Truncated)

90876523412674

(DataBar Omnidirectional Stacked)

78123465709811

(DataBar Omnidirectional Stacked)
