Codablock F

Product Reference Guide

325

Codablock F — cont.

Codablock F EAN Enable/Disable

Enables/Disables the Codablock F EAN subtype (code with FNC1 in the first position).

Codablock F AIM Check

Specifies if Check Digit calculation algorithm is AIM compliant or not.

ENTER/EXIT PROGRAMMING MODE

Codablock F EAN = Disable

Codablock F EAN = Enable

DEFAULT

ENTER/EXIT PROGRAMMING MODE

Codablock F AIM Check = Disable

Codablock F AIM Check = Enable Check C

DEFAULT
