Add-Ons

Product Reference Guide

155

Add-Ons — cont.

Optional GS1-128 Add-On Timer

This option sets the timer expiration value to read the added part after reading the linear

EAN/UPC part. For UPC/EAN add-ons other than those of that type, see Optional

Add-On Timer on page 152

ENTER/EXIT PROGRAMMING MODE

Optional GS1-128 Add-On Timer = Disable

Optional GS1-128 Add-On Timer = 10ms

Optional GS1-128 Add-On Timer = 20ms

Optional GS1-128 Add-On Timer = 30ms

Optional GS1-128 Add-On Timer = 40ms

Optional GS1-128 Add-On Timer = 50ms

DEFAULT
