GTIN Formatting

Product Reference Guide

137

GTIN Formatting

This feature enables/disables the ability to convert UPC-E, UPC-A, EAN 8, and EAN

13 labels into the GTIN 14-character format.

NOTE

If add-on information is present on the base label prior to the conver-

sion taking place, the addon information will be appended to the con-

verted GTIN label.

ENTER/EXIT PROGRAMMING MODE

GTIN Formatting = Disable

GTIN Formatting = Enable

DEFAULT
