Codabar

Product Reference Guide

249

Codabar — cont.

Codabar Stitching

This option enables/disables stitching for Codabar labels. When parts of a Codabar bar-

code are presented to the reader with this feature enabled, the barcode parts will be as-

sembled by the reader’s software, and the data will be decoded if all barcode proofing

requirements are met.

ENTER/EXIT PROGRAMMING MODE

Codabar Stitching = Disable

Codabar Stitching = Enable

DEFAULT

Default Chapter1
