Symbologies

280

PowerScan

PBT7100 Cordless

Industrial 2 of 5 — cont.

Industrial 2 of 5 Length Control

This feature specifies either variable length decoding or fixed length decoding for the In-

dustrial 2 of 5 symbology.

Variable Length —

For variable length decoding, a minimum and maximum length

may be set.

Fixed Length —

For fixed length decoding, two different lengths may be set.

ENTER/EXIT PROGRAMMING MODE

Industrial 2 of 5 Length Control = Variable Length

Industrial 2 of 5 = Fixed Length

DEFAULT
