Product Reference Guide 367
Appendix A
Technical Specifications
Table 47 contains Physical and Performance Characteristics, User Environment and
Regulatory information. Table 48 provides Standard Cable Pinouts.
Table 47. Technical Specifications
Item Description
Physical Characteristics — Reader
Color
Ye l l o w / B l a ck
Black/Black
Dimensions
Height 7.5”/190 mm
Length 4.5”/115 mm
Width 3.0”/75 mm
Weight (battery included) Approximately 13.4 ounces/380 g
Physical Characteristics — Base Station
Color Black/Yellow
Dimensions
Height 1.8” (46 mm) — 5.45” (13.84cm) w/antenna
Length 9.5” (24.13cm)
Width 4.0” (10.16cm) — 4.75” (12.07cm) w/antenna
Weight 12.5 ounces/354 g
Electrical Characteristics — Base Station
Input Voltage
5 VDC +/- 5%
7 – 14 VDC
Input Power
Maximum Operating Power (charging dead battery)
Typical Operating Power (charging full battery)
Typical Standby Power
6.5 W (while charging)
1.4 W
1 W
Input Current
Maximum Operating Current
Typical Operating Current
Typical Operating Current (TX data)
Typical Standby Current (Idle)
1300 mA @ 5VDC
250 mA @ 5VDC
210 mA @ 5VDC
115 mA
Performance Characteristics
Light Source Dual LEDs
To Next Page
