368
PowerScan
TM
PBT7100 Cordless
Roll (Tilt) Tolerance ± 30° from normal
Pitch Tolerance ± 82°
Skew (Yaw) Tolerance ± 65°
Field of View
2” wide at 1” from the reader
7” wide at 7” from the reader
Depth of Field
100 mil: typical 5.1" to 208.7" (13 cm to 530 cm)
55 mil: typical 1.9" to 118.1" (4.7 cm to 300 cm)
40 mil: typical 0.8" to 94.5" (2 cm to 240 cm)
20 mil: typical 0.1" to 46.9" (0.3 cm to 119 cm)
13 mil: typical 0" to 31.5" (0.1 cm to 80 cm)
10 mil: typical 0" to 23.6" (0 cm to 60 cm)
7.5 mil: typical 0.1" to 17.3" (0.2 cm to 44 cm)
5 mil: typical 0.6" to 5.5" (1.5 cm to 14 cm)
Minimum Element Width 3 mil
Print Contrast Minimum 15% minimum reflectance
Decode Capability
UPC/EAN/JAN, P2 /P5 add-ons; Code 39; Italian Code 32; Code 128;
C128 ISBT; Code 128 add-ons; I 2 of 5; Datalogic 2 of 5; Standard 2 of 5;
Code 11; Codabar; EAN 128; Code 93; MSI; DataBar Omnidirectional,
DataBar Limited, DataBar Expanded.
Interfaces Supported
RS-232 Std., RS-232 Wincor-Nixdorf, RS-232 OPOS, IBM 46xx (ports 5B
and 9B), USB Com Std., USB Keyboard, USB Alternate Keyboard, USB-
OEM, Keyboard Wedge (AT with or w/o Alternate Key, IBM AT PS2 with or
w/o Alternate Key, PC-XT, IBM 3153, IBM Terminals 31xx, 32xx, 34xx,
37xx make only and make break keyboard, and Digital Terminals VT2x,
VT3xx, VT4xx, and Apple).
User Environment — Reader
Operating Temperature -4° to +122° F (-20° to +50° C)
Storage Temperature -40° to +140° F (-40° to +60° C)
Humidity
Operating: 5% to 90% relative humidity, non-condensing
Storage: 5% to 95% relative humidity, non-condensing
Drop Specifications 50 drops from 2 meters (6.5 feet) to concrete, -30°C to 50°C
Ambient Light Immunity Up to 100,000 LUX in sunlight.
Contaminants
Spray/rain
Dust/particulates
IEC 529-IPX5
IEC 529-IP6X
Beeper Loudness 84 dBA typical for operator at a distance of 19” (50cm)
Item Description
