Data Editing

108

PowerScan

PBT7100 Cordless

GS1-128 AIM ID

If Global AIM ID is disabled, the AIM ID for GS1-128 can be enabled/disabled inde-

pendently. The AIM ID for GS1-128 is a ]C1, ]C2 or ]C3.

AIM IDs for other symbologies can be enabled/disabled independently as well. Contact

Customer Support for assistance.

ENTER/EXIT PROGRAMMING MODE

GS1-128 AIM ID = Disable

GS1-128 AIM ID = Enable

DEFAULT
