Symbologies

210

PowerScan

PBT7100 Cordless

Interleaved 2 of 5 (I 2 of 5) — cont.

I 2 of 5 Minimum Reads

This feature specifies the minimum number of consecutive times an I 2 of 5 label must

be decoded before it is accepted as good read..

ENTER/EXIT PROGRAMMING MODE

I 2 of 5 Minimum Reads = 1

I 2 of 5 Minimum Reads = 2

I 2 of 5 Minimum Reads = 3

I 2 of 5 Minimum Reads = 4

DEFAULT
