Data Editing

114

PowerScan

PBT7100 Cordless

Label ID — continued

Label ID Control

This option controls whether a Label ID is disabled, or sent as a prefix or suffix for a given

symbology type.

ENTER/EXIT PROGRAMMING MODE

Label ID Transmission = Disable

Label ID Transmission = Enable as Prefix

Label ID Transmission = Enable as Suffix

CANCEL

Make a mistake? Scan the CANCEL barcode to abort and not

save the entry string. You can then start again at the beginning.

DEFAULT

Default Chapter1
