Codabar

Product Reference Guide

237

Codabar — cont.

Codabar Quiet Zones

This feature specifies the number of quiet zones for Codabar labels. Quiet zones are blank

areas at the ends of a barcode and are typically 10 times the width of the narrowest bar

or space in the label.

ENTER/EXIT PROGRAMMING MODE

Codabar Quiet Zones = Quiet Zone on one side

Codabar Quiet Zones = Quiet Zones on two sides

Codabar Quiet Zones = Auto

Codabar Quiet Zones = Virtual Quiet Zones on two sides

Codabar Quiet Zones = Small Quiet Zones on two sides

DEFAULT
