Symbologies

136

PowerScan

PBT7100 Cordless

UPC-E — cont.

UPC-E Minimum Reads

This feature specifies the minimum number of consecutive times a UPC-E label must be

decoded before it is accepted as good read..

ENTER/EXIT PROGRAMMING MODE

UPC-E Minimum Reads = 1

UPC-E Minimum Reads = 2

UPC-E Minimum Reads = 3

UPC-E Minimum Reads = 4

DEFAULT
