Symbologies

196

PowerScan

PBT7100 Cordless

Code 128 — cont.

Code 128 Minimum Reads

This feature specifies the minimum number of consecutive times a Code 128 label must

be decoded before it is accepted as good read..

ENTER/EXIT PROGRAMMING MODE

Code 128 Minimum Reads = 1

Code 128 Minimum Reads = 2

Code 128 Minimum Reads = 3

Code 128 Minimum Reads = 4

DEFAULT
