Symbologies

228

PowerScan

PBT7100 Cordless

Datalogic 2 of 5 — cont.

Datalogic 2 of 5 Interdigit Maximum Ratio

This feature specifies the maximum ratio between intercharacter space and module for

Datalogic 2 of 5.

ENTER/EXIT PROGRAMMING MODE

Datalogic 2 of 5 Interdigit Maximum Ratio = Disable

Datalogic 2 of 5 Interdigit Maximum Ratio = 1

Datalogic 2 of 5 Interdigit Maximum Ratio = 2

Datalogic 2 of 5 Interdigit Maximum Ratio = 3

Datalogic 2 of 5 Interdigit Maximum Ratio = 4

Datalogic 2 of 5 Interdigit Maximum Ratio = 5

DEFAULT
