ISBT 128

Product Reference Guide

289

ISBT 128 Concatenation Mode

Specifies the concatenation mode between Static and Dynamic.

NOTE

This option is only valid when ISBT 128 Concatenation is enabled (see page

288

).

ENTER/EXIT PROGRAMMING MODE

ISBT 128 Concatenation Mode = Static

ISBT 128 Concatenation Mode = Dynamic

DEFAULT
