BT Features

344

PowerScan

TM

PBT7100 Cordless

Beep Volume

Selects the beeper volume (loudness) of radio-specific beep indications. There are three

selectable volume levels.

ENTER/EXIT PROGRAMMING MODE

Beep Volume = Low

Beep Volume = Medium

Beep Volume = High

DEFAULT
