Datalogic 2 of 5

Product Reference Guide

231

Datalogic 2 of 5 — cont.

Datalogic 2 of 5 Stitching

This option enables/disables stitching for Datalogic 2 of 5 labels. When parts of a Data-

logic 2 of 5 barcode are presented to the reader with this feature enabled, the barcode

parts will be assembled by the reader’s software, and the data will be decoded if all bar-

code proofing requirements are met.

ENTER/EXIT PROGRAMMING MODE

Datalogic 2 of 5 Stitching = Disable

Datalogic 2 of 5 Stitching = Enable

DEFAULT
