ISBT 128

Product Reference Guide

291

ISBT 128 — cont.

ISBT 128 Force Concatenation

When enabled, this feature forces concatenation for ISBT.

ISBT 128 Advanced Concatenation Options

NOTE

This option is only valid when

ISBT 128 Concatenation is enabled.

(

see page 288).

ENTER/EXIT PROGRAMMING MODE

ISBT 128 Force Concatenation = Disable

ISBT 128 Force Concatenation = Enable

DEFAULT

NOTE

Use the Datalogic Aladdin Configuration Application or contact Cus-

tomer Support to set up pairs of label types for concatenation.
