Datalogic PowerScan PBT7100 - Page 164

Datalogic PowerScan PBT7100

424 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Loading...

Symbologies

154

PowerScan

TM

PBT7100 Cordless

Add-Ons — cont.

Optional Add-On Timer — cont.

ENTER/EXIT PROGRAMMING MODE

Optional Add-on Timer = 180ms

Optional Add-on Timer = 200ms

Optional Add-on Timer = 220ms

Optional Add-on Timer = 240ms

Optional Add-on Timer = 260ms

Optional Add-on Timer = 280ms

Optional Add-on Timer = 300ms
