Code 128

Product Reference Guide

201

Code 128 — cont.

Code 128 Set Length 1 — cont.

ENTER/EXIT PROGRAMMING MODE

Select Code 128 Set Length 1 Setting

Make a mistake? Scan the CANCEL barcode to abort and not

save the entry string. You can then start again at the beginning.

CANCEL

DEFAULT

01 = Length 1 is 1 Character
