General Features

34

PowerScan

TM

PBT7100 Cordless

Scan Mode — continued

ENTER/EXIT PROGRAMMING MODE

Scan Mode = Trigger Single

Scan Mode = Trigger Hold Multiple

Scan Mode = Trigger Pulse Multiple

Scan Mode = Flashing

Scan Mode = Always On

Scan Mode = Stand Mode

Scan Mode = Trigger Object Sense

DEFAULT
