RS-232 ONLY Interface

48

PowerScan

TM

PBT7100 Cordless

Baud Rate — continued

ENTER/EXIT PROGRAMMING MODE

Baud Rate = 9600

Baud Rate = 19,200

Baud Rate = 38,400

Baud Rate = 57,600

Baud Rate = 115,200

DEFAULT
