Keyboard Interface

80

PowerScan

TM

PBT7100 Cordless

Wedge Quiet Interval — cont.

ENTER/EXIT PROGRAMMING MODE

Select Wedge Quiet Interval Setting

Make a mistake? Scan the CANCEL barcode to abort and not

save the entry string. You can then start again at the beginning.

CANCEL

DEFAULT

10 = Quiet Interval of 100 ms
