Keyboard Interface

84

PowerScan

TM

PBT7100 Cordless

Intercode Delay — cont.

ENTER/EXIT PROGRAMMING MODE

Set Intercode Delay

Make a mistake? Scan the CANCEL barcode to abort and not

save the entry string. You can then start again at the beginning.

CANCEL

DEFAULT

00 = No Wedge Intercode Delay
