103

4.13.5 DSE2157 RELAY MODULES

Select the DSENet ID of the relay expansion you wish to configure. The ID of the relay board is set by rotary

decimal switch accessible under the removable cover of the device.

The following is then shown:

Click to enable or disable the option.

The relevant values below will appear

greyed out if the option is disabled.

Select the alarm type of the link lost

alarm. This alarm will take action if the

expansion module is not detected by

the host module.

Select the output source and the

polarity required. For example this

output will energise when the module is

in the

Auto

mode.
