Deep Sea Electronics Plc DSE8810

Edit Configuration
42
4.7 GENERATOR
The generator page is subdivided into smaller sections.
Select the required section with the mouse.
4.7.1 GENERATOR OPTIONS
These parameters are described overleaf...
Click to enable or
disable the feature.
The relevant values
below appear
greyed out if the
feature is disabled.
If there is no input
configured to Generator
Closed Auxiliary this
option is greyed out
Click to enable or
disable the feature.
The relevant values
below appear
greyed out if the
feature is disabled.
Select your AC
system. A schematic
is shown below with
connection details
from the alternator
to the DSE8600
Series module.
