Edit Configuration
74
4.8.6 CRANKING
Crank disconnect settings are used to detect when the set fires during the starting sequence.
As the set is cranked, the first parameter that passes it’s crank disconnect setting will result in the cessation of
the cranking signal.
Having more than one crank disconnect source allows for a much faster crank disconnect response leading to
less wear on the engine and starter components, and provides added safety in case one source is lost, by a
blown or tripped fuse for example.
Click and drag to change the
setting.
Type the value
or click the up
and down
arrows to
change the
settings
If check oil pressure prior to
starting is enabled, the cranking
will not be allowed if the oil
pressure is not seen as being
low. This used as a double check
that the engine is stopped before
When enabled, releasing the start
button during a manual start will also
disconnect the crank.
Manual Crank Limit is provided to
protect the engine from being
cranked too long in case of a start
failure.
