Scada
122
5.3 LANGUAGES
5.4 DIGITAL INPUTS
State of the input
(open or closed to
battery negative)
State of the Emergency stop
input (open or closed to
battery positive).
This input MUST be closed
to battery positive for normal
operation.
If the input is open, the set
will be stopped if it’s already
running and will not be
allowed to start.
Shows if the input channel is active
or not. This input is open but is
active. The input is configured to be
open to activate
Shows if the input channel is active or not. This input is closed
and is active. The input is configured to be close to activate
Select new
language
Click to send the
new language to the
module
