Dummy Load Control
Provides control of configurable outputs set to Dummy Load Control.
= Dummy Load Control is disabled.
= The module will monitor the load and control any outputs configured to Dummy
Load Control (1-5)
Outputs in scheme: The amount of Dummy Load Control outputs that will be
included in the function.
Trip / Trip Delay: If the load level is below the Trip setting for the duration of the
Trip Delay, then the ‘next’ output configured to Dummy Load Control is activated
(max 5)
Return / Return Delay: If the load level is above the Return setting for the duration
of the Return Delay, then the ‘highest numbered’ output configured to Dummy Load
Control is de-activated and the timer is reset.
Continued overleaf...
Click to enable or
disable the option.
The relevant values
below will appear
greyed out if the
feature is disabled.
Click to enable or
disable the option.
The relevant values
below will appear
greyed out if the
feature is disabled.
