Deep Sea Electronics Plc DSE8810 Software Manual

Edit Configuration
15
4.4 INPUTS
The inputs page is subdivided into smaller sections.
Select the required section with the mouse.
4.4.1 OIL PRESSURE
Click to edit the
‘sensor curve’. See
section entitled Editing
the sensor curve
.
Enable or disable the
alarms. The relevant
values below will
appear greyed out if
the alarm is disabled.
Select the
sensor type
Click and drag to
change the settings
Type the value or click
the up and down arrows
to change the settings
If an engine ECU is
selected, this instructs
the module to bypass
ECU data for oil
pressure reading.
An alarm will be
triggered if the sensor
is disconnected from
the module.
