057-004 Electronic Engines and DSE wiring
057-045 DSE Guide to Synchronising and Load Sharing Part1
057-046 DSE Guide to Synchronising and Load Sharing Part2
057-047 DSE Load Share Design and Commissioning Guide
057-163 DSE8800 Operator manual
057-082 DSE2130 input expansion manual
057-139 DSE2131 input expansion manual
057-140 DSE2133 input expansion manual
057-141 DSE2152 input expansion manual
057-083 DSE2157 input expansion manual
057-084 DSE2548 input expansion manual
The following third party documents are also referred to:
1-55937-879-4 IEEE Std C37.2-1996 IEEE Standard Electrical Power System Device Function Numbers
and Contact Designations. Published by Institute of Electrical and Electronics Engineers
Inc
2 DESCRIPTION
This manual covers the operation of the DSE Configuration Suite for DSE8810 Colour Autostart Load Share
Controller. Separate manuals cover the remaining DSE modules supported by the software.
The DSE Configuration Suite allows the Controller to be connected to a PC via USB ‘A –USB B’ cable. Once
connected the various operating parameters within the module can be viewed or edited as required by the
engineer. This software allows easy controlled access to these values and also has diagnostic monitoring
facilities.
The configuration suite should only be used by competent, qualified personnel, as changes to the operation of
the module may have safety implications on the panel / generating set to which it is fitted. Access to critical
operational sequences and settings for use by qualified engineers, may be barred by a security code set by
the generator provider.
The information contained in this manual should be read in conjunction with the information contained in the
appropriate module documentation. This manual only details which settings are available and how they may
be used.
A separate manual deals with the operation of the individual module (See section entitled Bibliography
elsewhere in this document).
3 INSTALLATION AND USING THE DSE CONFIGURATION SUITE
SOFTWARE
For information in regards to instating and using the DSE Configuration Suite Software please refer to DSE
publication: 057-151 DSE Configuration Suite PC Software Installation & Operation Manual which can
be found on our website: www.deepseaplc.com
