Scada
123
5.5 DIGITAL OUTPUTS
State of the
output (open or
closed)
Shows if the output channel is active or not.
This output is closed but is active. The
output is configured to be Open Gen Output.
As the relay is normally closed (N/C) and the
Close Generator source is not present, the
relay is activated to open the N/C relay.
