Figure 7.6 Example hardware module terminals for a digital input (DI)
Here you can configure various settings for the terminal, subject to the type of terminal and hardware module selected.
INFO
The actual features you can select or configure are also subject to the type of hardware module you have selected.
Option Notes DI DO AI AO/PWM
I/O name
Configure I/O name. ● ● ● ●
Relay
Configure relay. ●
Sensor
Configure analogue input settings. ●
Output setup
Configure analogue output or PWM settings. ●
Functions
Assign function(s) to the I/O. ● ● ● ●
Alarm
Assign alarm(s) to the I/O. ● ● ● ●
7.7 Digital input (DI)
7.7.1 Configure I/O name
To rename the input or output name:
1. Select I/O name
I/O name
.
• The virtual keyboard is displayed on screen to edit the I/O name.
