10.5.3 View or configure display unit communication
Table 10.2 Display unit communication settings
Setting Range Default Notes
IPv6 address No default
DNS preferred 0.0.0.0, 255.255.255.255 * No default
DNS alternate 0.0.0.0, 255.255.255.255 * No default
IP address mode * Static, Auto Auto
Select Static to specify an IPv4
address.
IPv4 address 0.0.0.0, 255.255.255.255 * No default
Static IPv4 address for the
controller.
Netmask 0.0.0.0, 255.255.255.255 * No default Depends upon IPv4 address.
Default gateway 0.0.0.0, 255.255.255.255 * No default
NOTE * This is the range of addresses that you can select. The range of addresses that you can actually use depends on your
network design. If you select Static, then you must give the controller a unique IPv4 address. In addition, some addresses
in this range are reserved.
Figure 10.4 Display unit communication screen
View or configure display unit communication settings
To view or configure the display unit communication information, perform the following steps:
1. Select Tools , from the Home menu.
2. Select Communication to view the communication settings for the controller.
• The default page shown is the controller communication.
3. Select Display
.
4. Select the information to configure by pressing OK .
NOTE
Some information is not configurable on some controller types. A message displays when you cannot change
the information.
• Either the virtual keyboard or a selection choice is displayed on screen.
• Make the required changes or selection.
• Select Next
OPERATOR'S MANUAL 4189341099G UK Page 113 of 130
