Status text* Description
Ready for operation
All operation conditions are met. Gensets are ready to start
and/or breakers are ready to close.
● ● ● ●
SC in operation
A power supply from the shore connection is available, and
shore connection breaker is closed.
●
SC not ready
The shore connection is not ready to provide power to the
busbar. There may be alarms blocking the shore connection
breaker from closing.
●
SC ready
A power supply from the shore connection is available, and
shore connection breaker is open.
●
SG in operation
The shaft generator is producing power, and shaft generator
breaker is closed.
●
SG not ready
The shaft generator is not ready to provide power to the
busbar. There may be alarms blocking the shaft generator
breaker from closing.
●
SG ready
A power supply from the shaft generator is available, and shaft
generator breaker is open.
●
Start prepare - # s
The remaining time (in seconds) for the genset to prepare to
start.
●
Stop coil activated - # s
The remaining time (in seconds) before the genset shuts
down.
●
Switchboard control The controller is under switchboard control. ● ● ● ●
Synchronising GB ...
The controller is synchronising the genset to the busbar
frequency and voltage to close the generator breaker.
●
Synchronising sections ...
The controller is broadcasting the set points for
synchronisation.
●
Synchronising SCB ... The controller is broadcasting a set point for synchronisation. ●
Synchronising SGB ... The controller is broadcasting a set point for synchronisation. ●
Waiting for software ... A software update is in progress. ● ● ● ●
*Note: "# s" typically represents a timer countdown.
2.2.2 Operator information messages
When a situation arises that makes an operator information message relevant, it is shown in a blue box on the display unit screen
for a few seconds.
Table 2.2
Controller types
Icon Notes
GENSET controller
SHAFT generator controller
OPERATOR'S MANUAL 4189341099G UK Page 11 of 130
