Icon Notes
SHORE connection controller
BUS TIE breaker controller
Operator info Additional information
Alarm blocking engine start
A block alarm is active. Clear the alarm before attempting
to start the genset.
●
Alarm blocking GB / SGB /
SCB / BTB close
A block alarm is active. Clear the alarm before attempting
to close the breaker.
● ● ● ●
Breaker already closed
The breaker is already closed and cannot be closed
again.
● ● ● ●
Breaker already opened The breaker is already open and cannot be opened again. ● ● ● ●
BTB close blocked
The Block BTB close function is active. An open breaker
cannot be closed.
●
BTB close cancelled The BTB close was cancelled by a BTB open command. ●
BTB close not possible in
SWBD
While the controller is under switchboard control, operator
actions cannot be performed from the controller interfaces.
●
BTB close unblocked The Block BTB close function is not active. ●
BTB open cancelled The BTB open was cancelled by a BTB close command. ●
BTB open not possible in
SWBD
While the controller is under switchboard controller,
operator actions cannot be performed from the controller
interfaces.
●
Change of synchronisation
settings not possible in
SWBD
The input from the static synchronisation or dynamic
synchronisation digital input is ignored when the controller
is under switchboard control.
● ● ● ●
Dynamic synchronisation
activated
The digital input is activated. The controller will use
dynamic synchronisation.
● ● ● ●
Dynamic synchronisation
deactivated
The digital input is deactivated. The controller will use the
synchronisation type configured in the parameter.
● ● ● ●
Engine already running
The engine is already running and cannot be started
again.
●
Engine already stopped
The engine has already stopped and cannot be stopped
again.
●
Engine stopping ...
The command has already been received. The controller
is executing the engine stop procedure.
●
Engine not ready
The genset cannot start. There might be alarms blocking
the ready status.
●
Engine start and breaker
close not possible in SWBD
While the controller is under switchboard control, operator
actions cannot be performed from the controller
interfaces.
●
Engine start blocked
The Block engine start function is active. A stopped genset
cannot be started.
●
