You can create multiple instances of this route map by using the sequence number option to place the route maps in the correct order.
Dell Networking OS processes the route maps with the lowest sequence number rst. When a congured route map is applied to a
command, such as redistribute, trac passes through all instances of that route map until a match is found. The following is an
example with two instances of a route map.
The following example shows matching instances of a route-map.
Dell#show route-map
route-map zakho, permit, sequence 10
Match clauses:
Set clauses:
route-map zakho, permit, sequence 20
Match clauses:
interface GigabitEthernet 1/1
Set clauses:
tag 35
level stub-area
Dell#
To delete all instances of that route map, use the no route-map map-name command. To delete just one instance, add the sequence
number to the command syntax.
Dell(conf)#no route-map zakho 10
Dell(conf)#end
Dell#show route-map
route-map zakho, permit, sequence 20
Match clauses:
interface GigabitEthernet 1/1
Set clauses:
tag 35
level stub-area
Dell#
The following example shows a route map with multiple instances. The show config command displays only the conguration of the
current route map instance. To view all instances of a specic route map, use the show route-map command.
Dell#show route-map dilling
route-map dilling, permit, sequence 10
Match clauses:
Set clauses:
route-map dilling, permit, sequence 15
Match clauses:
interface Loopback 23
Set clauses:
tag 3444
Dell#
To delete a route map, use the no route-map map-name command in CONFIGURATION mode.
Congure Route Map Filters
Within ROUTE-MAP mode, there are match and set commands.
• match commands search for a certain criterion in the routes.
• set commands change the characteristics of routes, either adding something or specifying a level.
When there are multiple match commands with the same parameter under one instance of route-map, Dell Networking OS does a match
between all of those
match commands. If there are multiple match commands with dierent parameters, Dell Networking OS does a
match ONLY if there is a match among ALL the match commands. In the following example, there is a match if a route has any of the tag
values specied in the
match commands.
112
Access Control Lists (ACLs)

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
