monitored interface. Flow monitoring is supported for standard and extended IPv4 ACLs, standard and extended IPv6 ACLs, and standard
and extended MAC ACLs.
CONFIG-STD-NACL mode
seq sequence-number {deny | permit} {source [mask] | any | host ip-address} [count [byte]]
[order] [fragments] [log [threshold-in-msgs count]] [monitor]
If you congure the flow-based enable command and do not apply an ACL on the source port or the monitored port, both ow-based
monitoring and port mirroring do not function.
You cannot apply the same ACL to an interface or a monitoring session context simultaneously.
The port mirroring application maintains a database that contains all monitoring sessions (including port monitor sessions). It has
information regarding the sessions that are enabled for ow-based monitoring and those sessions that are not enabled for ow-based
monitoring. It downloads monitoring conguration to the ACL agent whenever the ACL agent is registered with the port mirroring
application or when ow-based monitoring is enabled.
The show monitor session session-id command displays the Type eld in the output, which indicates whether a particular
session is enabled for ow-monitoring.
Example Output of the show Command
Dell# show monitor session 1
SessID Source Destination Dir Mode Source IP Dest IP DSCP
TTL Drop Rate Gre-Protocol FcMonitor
------ ------ ----------- --- ---- --------- -------- ----
--- ---- ---- ----------- ---------
1 Gi 1/45 Gi 1/46 tx Port 0.0.0.0 0.0.0.0 0
0 No N/A N/A yes
Dell#
The show config command has been modied to display monitoring conguration in a particular session.
Example Output of the show Command
(conf-mon-sess-11)#show config
!
monitor session 11
flow-based enable
source GigabitEthernet 1/1 destination GigabitEthernet 1/1 direction both
The show ip accounting commands have been enhanced to display whether monitoring is enabled for trac that matches with the
rules of the specic ACL.
Example Output of the show Command
Dell# show ip accounting access-list
!
Extended Ingress IP access list kar on GigabitEthernet 1/1
Total cam count 1
seq 5 permit ip 192.168.20.0/24 173.168.20.0/24 monitor
Dell#show ipv6 accounting access-list
!
Ingress IPv6 access list kar on GigabitEthernet 1/1
Total cam count 1
seq 5 permit ipv6 22::/24 33::/24 monitor
Access Control Lists (ACLs)
135
