• Modify the threshold for monitoring ECMP group bundles.
CONFIGURATION mode
link-bundle-distribution trigger-threshold {percent}
The range is from 1 to 90%.
The default is 60%.
• Display details for an ECMP group bundle.
EXEC mode
show link-bundle-distribution ecmp-group ecmp-group-id
The range is from 1 to 64.
Viewing an ECMP Group
NOTE: An ecmp-group index is generated automatically for each unique ecmp-group when you congure multipath routes to the
same network. The system can generate a maximum of 512 unique ecmp-groups. The ecmp-group indices are generated in even
numbers (0, 2, 4, 6... 1022) and are for information only.
You can congure ecmp-group with id 2 for link bundle monitoring. This ecmp-group is dierent from the ecmp-group index 2 that is
created by conguring routes and is automatically generated. These two ecmp-groups are not related in any way.
Dell(conf-ecmp-group-5)#show config
!
ecmp-group 5
interface gigabitethernet 1/2
interface gigabitethernet 1/3
link-bundle-monitor enable
Dell(conf-ecmp-group-5)#
Equal Cost Multi-Path (ECMP)
267

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
