Dell S3048-ON User Manual

However, these changes are backward-compatible and do not aect existing behavior; meaning, you can still use the ip http source-
interface command to communicate with a particular interface even if no VRF is congured on that interface
NOTE: If the HTTP service is not VRF-aware, then it uses the global routing table to perform the look-up.
To enable an HTTP client to look up the VRF table corresponding to either management VRF or any nondefault VRF, use the ip http
vrf
command in CONFIGURATION mode.
• Congure an HTTP client with a VRF that is used to connect to the HTTP server.
CONFIGURATION MODE
Dell(conf)#ip http vrf {management | <vrf-name>}
Getting Started 59

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
