ip pim [vrf vrf-name] rp-Candidate interface [priority] [acl-name]

The specied acl-list is associated to the rp-candidate.

NOTE: You can create the ACL list of multicast prex using the ip access-list standard

command.

PIM Source-Specic Mode (PIM-SSM) 597
