Applying a Class-Map or Input QoS Policy to a Queue
To apply a class-map or input QoS policy to a queue, use the following command.
• Assign an input QoS policy to a queue.
POLICY-MAP-IN mode
service-queue
Applying an Input QoS Policy to an Input Policy Map
To apply an input QoS policy to an input policy map, use the following command.
• Apply an input QoS policy to an input policy map.
POLICY-MAP-IN mode
policy-service-queue <number> qos-polcy
Honoring DSCP Values on Ingress Packets
Dell Networking OS provides the ability to honor DSCP values on ingress packets using Trust DSCP feature.
The following table lists the standard DSCP denitions and indicates to which queues Dell Networking OS maps DSCP values. When you
congure trust DSCP, the matched packets and matched bytes counters are not incremented in the show qos statistics.
Table 57. Default DSCP to Queue Mapping
DSCP/CP hex range
(XXX)xxx
DSCP Denition Traditional IP
Precedence
Internal Queue ID DSCP/CP decimal
111XXX Network Control 3 48–63
110XXX Internetwork Control 3 48–63
101XXX EF (Expedited
Forwarding)
CRITIC/ECP 2 32–47
100XXX AF4 (Assured
Forwarding)
Flash Override 2 32–47
011XXX AF3 Flash 1 16–31
010XXX AF2 Immediate 1 16–31
001XXX AF1 Priority 0 0–15
000XXX BE (Best Eort) Best Eort 0 0–15
• Enable the trust DSCP feature.
POLICY-MAP-IN mode
trust diffserv
Honoring dot1p Values on Ingress Packets
Dell Networking OS honors dot1p values on ingress packets with the Trust dot1p feature.
The following table species the queue to which the classied trac is sent based on the dot1p value.
Quality of Service (QoS)
647

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
