Dell S3048-ON User Manual

The following table displays the default values for RSTP.
Table 64. RSTP Default Values
RSTP Parameter Default Value
Forward Delay 15 seconds
Hello Time 2 seconds
Max Age 20 seconds
Port Cost:
• 100-Mb/s Ethernet interfaces
• 1-Gigabit Ethernet interfaces
• 10-Gigabit Ethernet interfaces
• Port Channel with 100 Mb/s Ethernet interfaces
• Port Channel with 1-Gigabit Ethernet interfaces
• Port Channel with 10-Gigabit Ethernet interfaces
Port Cost:
• 200000
• 20000
• 2000
• 180000
• 18000
• 1800
Port Priority 128
To change these parameters, use the following commands.
• Change the forward-delay parameter.
PROTOCOL SPANNING TREE RSTP mode
forward-delay seconds
The range is from 4 to 30.
The default is 15 seconds.
• Change the hello-time parameter.
PROTOCOL SPANNING TREE RSTP mode
hello-time seconds
NOTE
: With large congurations (especially those congurations with more ports) Dell Networking recommends
increasing the hello-time.
The range is from 1 to 10.
The default is 2 seconds.
• Change the max-age parameter.
PROTOCOL SPANNING TREE RSTP mode
max-age seconds
The range is from 6 to 40.
The default is 20 seconds.
To view the current values for global parameters, use the show spanning-tree rstp command from EXEC privilege mode.
Rapid Spanning Tree Protocol (RSTP)
691

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
