INTERFACE PORT-CHANNEL mode
vlan-stack {access | trunk}
2 Congure VLAN as VLAN-stack compatible on both the peers.
INTERFACE VLAN mode
vlan-stack compatible
3 Add the VLT LAG as a member to the VLAN-stack on both the peers.
INTERFACE VLAN mode
member port-channel port—channel ID
4 Verify the VLAN-stack congurations.
EXEC Privilege
show running-config
Sample conguration of VLAN-stack over VLT (Peer 1)
Congure the VLT domain
Dell(conf)#vlt domain 1
Dell(conf-vlt-domain)#peer-link port-channel 1
Dell(conf-vlt-domain)#back-up destination 10.16.151.116
Dell(conf-vlt-domain)#primary-priority 100
Dell(conf-vlt-domain)#system-mac mac-address 00:00:00:11:11:11
Dell(conf-vlt-domain)#unit-id 0
Dell(conf-vlt-domain)#
Dell#show running-config vlt
!
vlt domain 1
peer-link port-channel 1
back-up destination 10.16.151.116
primary-priority 100
system-mac mac-address 00:00:00:11:11:11
unit-id 0
Dell#
Congure the VLT LAG as VLAN-Stack Access or Trunk Port
Dell(conf)#interface port-channel 10
Dell(conf-if-po-10)#switchport
Dell(conf-if-po-10)#vlt-peer-lag port-channel 10
Dell(conf-if-po-10)#vlan-stack access
Dell(conf-if-po-10)#no shutdown
Dell#show running-config interface port-channel 10
!
interface Port-channel 10
no ip address
switchport
vlan-stack access
vlt-peer-lag port-channel 10
no shutdown
Dell#
Dell(conf)#interface port-channel 20
Dell(conf-if-po-20)#switchport
Dell(conf-if-po-20)#vlt-peer-lag port-channel 20
Dell(conf-if-po-20)#vlan-stack trunk
Dell(conf-if-po-20)#no shutdown
936
Virtual Link Trunking (VLT)
