Dell S3048-ON User Manual

Dell#show ip route vrf orange
Codes: C - connected, S - static, R - RIP,
B - BGP, IN - internal BGP, EX - external BGP,LO - Locally Originated,
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, i - IS-IS, L1 - IS-IS level-1,
L2 - IS-IS level-2, IA - IS-IS inter area, * - candidate default,
> - non-active route, + - summary route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
C 2.0.0.0/24 Direct, Vl 192 0/0 00:20:55
C 20.0.0.0/24 Direct, Gi 1/2 0/0 00:10:05
O 21.0.0.0/24 via 2.0.0.2, Vl 192 110/2 00:10:41
Dell#show ip route vrf green
Codes: C - connected, S - static, R - RIP,
B - BGP, IN - internal BGP, EX - external BGP,LO - Locally Originated,
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, i - IS-IS, L1 - IS-IS level-1,
L2 - IS-IS level-2, IA - IS-IS inter area, * - candidate default,
> - non-active route, + - summary route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
C 3.0.0.0/24 Direct, Vl 256 0/0 00:20:52
C 30.0.0.0/24 Direct, Gi 1/3 0/0 00:09:45
S 31.0.0.0/24 via 3.0.0.2, Vl 256 1/0 00:09:06
======================================================================================
The following shows the output of the show commands on Router 2.
Router 2
Dell#show ip vrf
VRF-Name VRF-ID Interfaces
default-vrf 0 Gi 3/0-3,
Gi 2/0-17,21-47,
Ma 0/0,
Ma 1/0,
Nu 0,
Vl 1
blue 1 Gi 2/1,
Vl 128
orange 2 Gi 2/2,
Vl 192
green 3 Gi 2/3,
Vl 256
Dell#show ip ospf 1 neighbor
Neighbor ID Pri State Dead Time Address Interface Area
1.0.0.1 1 FULL/BDR 00:00:36 1.0.0.1 Vl 128 0
!
Dell#sh ip ospf 2 neighbor
Neighbor ID Pri State Dead Time Address Interface Area
2.0.0.1 1 FULL/BDR 00:00:33 2.0.0.1 Vl 192 0
!
Dell#show ip route vrf blue
Codes: C - connected, S - static, R - RIP,
B - BGP, IN - internal BGP, EX - external BGP,LO - Locally Originated,
966
Virtual Routing and Forwarding (VRF)

Dell S3048-ON Specifications

General

Rack Units	1U
Form Factor	Rack-mountable
Input Voltage	100-240V AC
Power Supply	2 hot-swappable power supplies
Management	CLI, Web, SNMP
Product Type	Switch
MAC Address Table Size	32K entries
Jumbo Frame Support	Yes
Latency	< 3 microseconds
Ports	48 x 1GbE RJ45, 4 x 10GbE SFP+
