The VRID range is from 1 to 255.
2 Congure virtual IP addresses for this VRID.
INTERFACE -VRID mode
virtual-address ip-address1 [...ip-address12]
The range is up to 12 addresses.
Examples of the Conguring and Verifying a Virtual IP Address
The following example shows how to congure a virtual IP address.
Dell(conf-if-gi-1/1-vrid-111)#virtual-address 10.10.10.1
Dell(conf-if-gi-1/1-vrid-111)#virtual-address 10.10.10.2
Dell(conf-if-gi-1/1-vrid-111)#virtual-address 10.10.10.3
The following example shows how to verify a virtual IP address conguration.
NOTE: In the following example, the primary IP address and the virtual IP addresses are on the same subnet.
Dell(conf-if-gi-1/1)#show conf
!
interface GigabitEthernet 1/1
ip address 10.10.10.1/24
!
vrrp-group 111
priority 255
virtual-address 10.10.10.1
virtual-address 10.10.10.2
virtual-address 10.10.10.3
!
vrrp-group 222
no shutdown
The following example shows the same VRRP group (VRID 111) congured on multiple interfaces on dierent subnets.
Dell#show vrrp
------------------
GigabitEthernet 1/1,
VRID: 111,Version: 2 Net: 10.10.10.1
VRF: 0 default
State: Master, Priority: 255, Master: 10.10.10.1 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 1768, Gratuitous ARP sent: 5
Virtual MAC address:
00:00:5e:00:01:6f
Virtual IP address:
10.10.10.1 10.10.10.2 10.10.10.3 10.10.10.10
Authentication: (none)
------------------
GigabitEthernet 1/2, VRID: 111, Version: 2 Net: 10.10.2.1
VRF: 0 default
State: Master, Priority: 100, Master: 10.10.2.1 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 27, Gratuitous ARP sent: 2
Virtual MAC address:
00:00:5e:00:01:6f
Virtual IP address:
10.10.2.2 10.10.2.3
Authentication:
When the VRRP process completes its initialization, the State eld contains either Master or Backup.
