Delta Electronics AC Motor Drive VFD-VE Series - Page 84

Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-35
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
08-22
Wind Mode 0: Rewind
1: Unwind
0
○ ○ ○ ○ ○
08-23
Mechanical Gear Ratio
A
1-65535
100
○ ○ ○ ○ ○
08-24
Mechanical Gear Ratio
B
1-65535
100
○ ○ ○ ○ ○
08-25
Source of the Tension
Command/Line Speed
0: Parameter setting (Pr.08-26)
1: RS-485 communication setting (Pr.08-26)
2: Analog input (Pr. 03-00~03-02 is set to 14 PID
target value of tension, 03-00~03-02 is set to 12
line speed)
0
○ ○ ○ ○ ○
08-26
PID Target Value of
Tension/Line Speed
0.0~100.0%
50.0
○ ○ ○ ○ ○
08-27
Source of Tension/Line
Speed PID Feedback
0: Analog input (Pr. 03-00~03-02 is set to 11 PID
feedback of tension)
1: Pulse input (Pr.08-40)
0
○ ○ ○ ○ ○
08-28
Auto-tuning Tension
PID
0: Disable
1: Reel diameter (08-29~08-31corresponds to 08-
44, 08-32~08-34 corresponds to 08-43)
2: Frequency (08-29~08-31 corresponds to 01-07,
08-32~08-34 corresponds to 01-00)
○ ○ ○ ○ ○
08-29
Tension PID P1 0.0~1000.0
50.0
○ ○ ○ ○ ○
08-30
Tension PID I1 0.00~500.00 sec
1.00
○ ○ ○ ○ ○
08-31
Reserved
08-32
Tension PID P2 0.0~1000.0 50.0
○ ○ ○ ○ ○
08-33
Tension PID I2 0.00~500.00 sec 1.00
○ ○ ○ ○ ○
08-34
Reserved
08-35
PID/Line Speed Output
Status
0: Positive output
1: Negative output
0
○ ○ ○ ○ ○
08-36
Tension/Line Speed PID
Output Limit
0~100.00% (according to Pr,01-00) 20.00
○ ○ ○ ○ ○
08-37
Source of Line Speed
Input Command
0: Disable
1: Analog input (Pr. 03-00~03-02 is set to 12 line
speed)
2: RS-485 communication setting (Pr.08-41)
3: Pulse input (Pr.08-40)
4: DFM-DCM pulse input (Pr.02-18)
0
○ ○ ○ ○ ○
08-38
Max. Line Speed 0.0~3000.0m/min 1000.0
○ ○ ○ ○ ○
08-39
Min. Line Speed 0.0~3000.0m/min 0.0
○ ○ ○ ○ ○
08-40
Pulse Number for Each
Meter
0.0~6000.0 0.0
○ ○ ○ ○ ○
08-41
Current Line Speed 0.0~3000.0m/min 0.0
○ ○ ○ ○ ○
08-42
Source of Reel
Diameter
0: Calculated by line speed
1: Calculated by integrating thickness (encoder
is on reel shaft)(Pr.08-49~51, Pr.10-15)
2: Calculated by integrating thickness (encoder
is on motor)(Pr.08-23~08-24, 08-50~08-51, 10-
00~10-01)
3: Calculated by analog input (Pr.03-00~03-02 is
set to 13)
0
○ ○ ○ ○ ○
08-43
Max. Reel Diameter 1.0~6000.0mm 6000.0
○ ○ ○ ○ ○
08-44
Empty Reel Diameter 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-45
Source of Initial Reel
Diameter
0: RS-485 communication setting (Pr.08-46)
1: Analog input (Pr.03-00-Pr.03-02 is set to 13)
0
○ ○ ○ ○ ○
08-46
Initial Reel Diameter 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-47
Initial Reel Diameter 1 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-48
Initial Reel Diameter 2 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-49
Number of Pulse per
Revolution
1~10000ppr 1
○ ○ ○ ○ ○
08-50
Coil Number for Each
Layer
0.001~60.000mm 1.000
○ ○ ○ ○ ○
08-51
Material Thickness 0.001~60.000mm 1.000
○ ○ ○ ○ ○
08-52
Filter Time of Reel
Diameter
0.00 to 100.00 seconds 1.00
○ ○ ○ ○ ○
08-53
Auto Compensation of 0: Disable 1.00
○ ○ ○ ○ ○
